ELIOT low-power microcontroller

ELIOT LOW-POWER MICROCONTROLLER

ELIoT

ELIoT is a low-power SoC microcontroller for control and navigation systems, for example, industrial IoT, smart sensors and trackers. This high-performance SoC is manufactured using CMOS 40 nm process. ELIoT features two ARM Cortex-M33 CPU cores, a GLONASS/ GPS navigation core and embedded input-output ports.

ELIoT specifications:

  • ARM Cortex-M33 CPU1 core with FPU support, clock rate – up to 150 MHz.

  • ARM Cortex-M33 CPU0 core, clock rate – up to 50 MHz.

  • FLASH memory: 640 KB.

  • SRAM memory: 320 KB.

  • OTP memory: 1 KB.

  • GLONASS/GPS navigation core.

  • Quad SPI external memory interface.

  • USB 2.0 OTG controller.

  • SD 3.0/MMC 4.51 port.

  • SRAM/PSRAM/NOR FLASH memory port.

  • CAN port.

  • 2 DMA controllers.

  • 4 UART ports.

  • 3 SPI ports.

  • 2 I2C ports.

  • I2S port.

  • 2 PWM controllers, 8 channels each.

  • 4 GPIO ports, 16 outputs each.

  • RTC, WDT, TIM timer unit.

  • JTAG debugging interface.

  • Embedded temperature and voltage sensors.

  • Power supply – 3.3 V.

  • Package type: LFBGA-132, 7 x 7 mm.

  • Manufacturing process – TSMC 40ULP.

Название документа

Дата

Размер

Скачать

Вся документация

WDT/RTC/ Timers AMBA 5 AHB Interconnect UART 4 ports CAN SPI 3 ports I2C 2 ports Quad SPI Memory port SRAM 2xDMA CPU0 ARM Cortex-M33 CPU1 ARM Cortex-M33 FPU SD/MMC USB 2.0 GPIO 64 outputs I2S GLONASS/ GPS PWM 16 channels
