ROBODEUS processor

ROBODEUS PROCESSOR

RoboDeus

RoboDeus is a multi-core SoC microprocessor for advanced devices with video analysis support. The IC can be used in cognitive servers, autonomous robotic complexes and multi-media applications as well as for completing neural network learning tasks.

RoboDeus high-performance SoC microprocessor is manufactured using 16-nm CMOS technology. The IC includes MIPS64 8-core coherent CPU cluster, ELcore-50 based on 16 DSP cores, a navigation core with GLONASS/GPS/BeiDou/GALILEO support and embedded input/ output ports.

Performance specifications of RoboDeus:

  • Manufacturing technology – CMOS 16 nm, TSMC process.

  • Maximum operating frequency, MHz – 1500 (CPU)/600-1000 (DSP)/600 (GPU).

  • Total power consumption of the microprocessor – 100 W or less, minimizable.

  • Embedded L3 cache - 16 MB.

  • Dedicated Low Power Management hardware unit.

  • Power voltage:

    • core power supply 1–1.2 V;

    • adjustable peripheral power supply 1.8/2.5/3.3 V.

  • Package type: 2071 HFCBGA.

  • Multicore heterogeneous MIMD-architecture based on standard and specialized processor cores:

    • coherent control cluster including 8 MIPS64 I6500 CPU cores with the operating frequency of up to 1500 MHz;

    • MIPS64 I6400 server processor CPU core for system control;

    • a high-performance cluster based on 16 ELcore-50 DSP cores with IC resources and external memory management capability, compatible with DELcore product line with the floating and fixed points.

  • Peak performance of the DSP cluster:

    • 1 TFLOPs DP (FP64);

    • 4 TFLOPs SP (FP32);

    • 16 TFLOPs HP (FP 16).

  • Total data and program memory of the cluster – 16 MB.

  • Peak performance of one DSP core (operations per clock cycle):

    • 64 MAC in FP64 format;

    • 256 MAC in FP32 format;

    • 1024 MAC in FP16 format;

    • 8 MAC in INT64 format;

    • 64 MAC in INT32 format;

    • 256 MAC in INT16 format;

    • 1024 MAC in INT8 format.

  • Support of backup reconfigurable control circuit.

  • Embedded graphic accelerator (PowerVR Series8XT GT8540): 4 coherent cores with the operating frequency of at least 600 MHz based on PowerVR 8XT GT8540 graphic core.

  • Peak performance of GPU:

    • 230 GFLOPs – in FP32 format;

    • 460 GFLOPs - in FP16 format.

  • Supported standards: OpenGL, OpenCL, OpenVG.

  • Support of pGPU mode with API OpenCL.

  • Embedded multi-functional ISP preprocessor.

  • Embedded video coding/ decoding core:

    • in the coding mode:

      • 2 multi-standard coders supporting H.265 (HEVC) and H.264 formats and all main profiles, coding speeds:

        • 1x 4K UHD (3840х1080) 60 fps;

        • 2x 4K UHD (3840х1080) 30 fps;

        • 8x Full HD (1920х1080) 30 fps;

      • simultaneous coding of up to 8 streams (4 streams per coder);

      • separate coding unit for JPEG and M-JPEG standards: up to 1 GPX/s, UHD resolution – 60 fps;

    • in the decoding mode:

      • 2 multi-standard coders supporting H.265 (HEVC) and H.264 formats and all main profiles;

      • simultaneous coding of up to 8 streams (4 streams per coder);

    • for coder/ decoder modes:

      • resolution of up to 8К;

      • colour depth – up to 10 bits per channel;

      • colour downsampling 4:0:0, 4:2:0, 4:2:2;

      • embedded microcontrollers for coding/ decoding control.

  • 4-standard navigation core, ГЛОНАСС/GPS/BeiDou/GALILEO.

  • Peripherals:

    • 4 DDR4 ports with 72-bit data buses (with ECC and CRC system support), bit rate - 819 Gbit/s;

    • 4 controllers with 4 PCI Express 4.0 lines each, bit rate - 16 GT/s per line;

    • 2 Ethernet MAC 1 Gbit controllers;

    • MAC Ethernet 10 Gbit + PHY;

    • NAND Flash controller with ECC (ONFI 2.2, 8/16 bit, 200 MT/s);

    • 2 SATA 3.0 controllers, bit rate - 6 GT/s each;

    • 2 USB 3.1 ports + PHY, 10 GT/s each;

    • 64 GPIO lines;

    • 3 SD/MMC ports (SDHC/SDXC, UHS-I, 104 Mbit/s) with eMMC 4.5 support;

    • 4 UART ports of 16550А type with IrDA support;

    • 4 I2C ports;

    • 2 dedicated SPI ports;

    • a dedicated I2S port;

    • a multifunctional LCD-display controller with the pixel clock of 594 MHz, HDMI video output support with the resolution of 3840x2160p60;

    • 2 MFBSP multifunctional ports (LPORT, SPI, I2S, GPIO) with an embedded DMA controller;

    • 2 MIPI CSI2 ports with the capability to connect 2 cameras, CMOS, HiSPI, LVDS interface support;

    • 8 universal 32-bit timers;

    • NOC-based switching system (Network-on-Chip) with embedded security and virtualization system;

    • MIPS EJTAG debugging and tracing architecture, IEEE1149.1-compliant (JTAG) debugging procedure, a debugging port with internal IC memory access, a subsystem for real-time program trace collection from CPU and DSP, trace output via an external port, a power management controller.

  • Software tools:

    • С/C++ compiler for CPU unit;

    • С/С++/C11 compiler for DSP unit;

    • OpenCL compiler framework for GPU;

    • a binutils-based binary utility pack: assembler, disassembler, linker, librarian;

    • hardware support of primitives used in DNN neural networks.

  • Integrated development and debugging environment:

    • software development tools, IC simulator and debugging tools include:

      • profiling tools for program execution on CPU;

      • profiling tools for program execution on GPU;

      • profiling tools for program execution on DSP;

      • project creation, project file compilation and project assembly yielding executable code and debugging with a program simulator and debugging board for SoC

      • program code entry and processing;

      • file compilation and program assembly;

      • syntax error detection and visual highlighting;

      • preparation of store image for loading to the target device;

      • program debugging;

    • IC simulator provides program imitation of processor core commands as well as working with memory, graphic processor (support of OpenGL and other API for GPU) and IC peripherals;

    • debugging tools provide debugging using the IC simulator and directly on the IC through JTAG port of the IC and USB port of the source computer, as well as:

      • loading programs into the memory model;

      • specifying breakpoints at a program address or a code line;

      • program launch;

      • program execution until the breakpoint or by steps, via the called function or skipping the called function;

      • informing about program halts and completion;

      • data reading from simulator memory by address or symbolic variable name at program halts;

      • data reading from memory and simulator (or IC) registers, data writing to memory and simulator registers of the IC;

      • boot loader program for creating a backup reconfigurable control circuit inside the IC.

Название документа

Дата

Размер

Скачать

Вся документация

MIPI CSI 2 s port ISP HEVC/H.264 Encoder 1 HEVC/H.264 Encoder 0 JPEG/M-JPEG Encoder CPU Pcle 4.0 4 s port USB 3.1 2 s port UART 4 s port SD/MMC 3 s port SATA 3.0 2 s port SPI 2 s port 2x CMOS 2x HiSPI 2x LVDS GPIO output 64 s HDMI PDP I2S I2C 4 s port M emory port NAND FLASH Ethernet 1000 2 s port Ethernet 10G L3 CACHE DDR4 L3 CACHE DDR4 DDR4 DDR4 L3 CACHE L3 CACHE DSP Elcore-50 Quad DSP Elcore-50 Quad DSP Elcore-50 Quad DSP Elcore-50 Quad GLONASS/GPS/BeiDou/GALILEO GPU 8XT Quad MIPS64 Quad MIPS64 Quad HEVC/H.264 Decoder 0 HEVC/H.264 Decoder 1
